Cassava chips making machine is equipment that can cut or slice big lumps of raw material roots into small chips, often used for chips making like cassava tubers, potatoes and sweet potatoes and so on. Durable material, High production rate, and adjustable output thickness.

Large scale cassava chips making machine

The working principle of cassava chips making machine

Cassava roots will be fed into the machine by inlet hopper, and then sliced by knives installed on a rotated drum. The rotated drum rotates in the electric motors rotation and cutting knife-edge direction. When moving from cassava in a straight line towards the disk, cassava roots will be sliced by the rotating cutting blades. After slicing, chips will drop down into belt conveyor and be sent out. And the thickness of final chips can be adjusted between 5-20mm.

Details of cassava chips making machine

The constitution details of cassava chips making machine

Cassava chips making machine mainly consists of the main frame, couplings, peeling roll cage, the motor or the diesel engine and other parts, of which the main frame by feeding hopper, slicing device and belt conveyor. And for the slicing device of cassava chips making machine, it is composed of blades and rotated drum, the number of blades can be chosen according to the expecting capacity.

Cassava chips making machine in Jinrui factory

The characteristics of cassava chips making machine

Made of high quality and thickness carbon steel, ensuring long service life of equipment;

Available for driven by electrical motor or diesel engine, meeting the specific requirements of different customers;

Special blades design on rotated drum, improving the efficiency of production;

Adjustable output sizes, satisfying different output thickness requirements.

Apart from the cassava chips making machine, Henan Jinrui company can also supply cassava rasper, installed after chips making machine to further crush cassava slices up down to cassava mush, which can be finally transmuted into cassava flour or cassava starch according to the invest tendency of clients. If you have such plan to set up a cassava chips processing factory and would like to know more about related equipment or processing lines, feel free to contact us to get more details.

• Introduction
• Parameter

The performance parameter of cassava chips making machine

Model	DYQP-01
Weight	1100kg
Engine	Electric or diesel
Power	5.5KW/5.67kw
Cutter	6 blades
Cutter disc	Diameter1000mm
Cutter speed	450~650r/min
Productivity	5t/h
Chip thickness	5-20mm (adjustable)
Size	2300×1750×2200mm
Material	carbon steel
